Wear Resistant Single Screw Barrel Corrosion Resistant Screw Injection Machine 60mm

Basic Information

Place of Origin:	Made in Suzhou, China
Brand Name:	KTL
Certification:	ISO9001
Model Number:	Diameter:16-60

Minimum Order Quantity:	1pc
Price:	Starting from 580 US dollars
Packaging Details:	Composite eco-friendly wooden box
Delivery Time:	60 to 90 days
Payment Terms:	T/T
Supply Ability:	300 pcs

Get Best Price

Chat Now

Detail Information

Component :	Screw 、Screw Tip Assembly 、Barrel Head (Flange) Nozzle	Material:	All-Hard Alloy
Main Alloy Composition:	Main Alloy Composition	Heat Treatment Process:	Quenching
Material :	KTL-ST30 Double Alloy (Fe-Ni Base)	Main Alloy Composition :	Inner Alloy: Fe, Ni, Cr, C, Co, B
Structure :	Double Alloy Structure (iron-nickel Base + Inner Alloy Layer)	Hardness :	Base: HRC 26–28
Highlight:	Wear Resistant Single Screw Barrel , Single Screw Barrel Corrosion Resistant , injection machine screw 60mm

Product Description

Wear-Resistant and Corrosion-Resistant Screw For Mobile Field

High-performance injection molding screw engineered for exceptional durability in demanding mobile industry applications.

Technical Specifications

Product Material	Special metallurgical steel powder
Compatible Machinery	Electric injection molding machine, oil hydraulic injection molding machine (maximum temperature ≤ 500°C)
Material Origin	Europe
Main Components	Cr, Mo, V, Ni, Co, etc.
Material Characteristics	High-temperature quenching, high-temperature tempering, and tail end high-temperature annealing softening treatment with excellent surface finish
Heat Treatment Technology	Vacuum quenching at 1150-1180°C, followed by 550-600°C high-temperature tempering (4+ cycles), tail high-temperature annealing softening treatment. Hardness: HRC 52-55

Manufacturing Procedure

Rough turning
Heat treatment
CNC thread grinding
Lathe finishing
CNC milling
Grinding
Polishing
Quality control
Packaging

Quality Control Process

Heat treatment indicators inspection - Each machining process inspection - Finished products inspection

Application Range

Suitable for GF < 50% highly acidic plastic pellets including PA66, PA46, PBT, PEEK, PPSU, PEI, and PPA.
